ESF12B Vibratory Hammer

ESF12B Vibratory Hammer

ESF12 size vibratory hammer is attached to 47-50 tons class excavators. Alternatively, it can be operated by power pack unit like PS 300. ESF 12 Vibratory Hammer is the biggest excavator size vibratory hammer and can drive sheet piles or steel tubes up to 15 meters in hard ground formations.












Excavator Class

45-50 tons

Centrifugal Force

934 kN

Eccentric Moment

12.6 kgm

Speed

2600 rpm

Pulling Force

200 kN

Push Down

200 kN

Total Weight (incl. Clamp)

2350 kg

Dynamic Weight (incl. Clamp)

1700 kg

Amplitute

14.8 mm

Power

185 kW

Displacement

315 liter/min

Working Pressure

300 bar

Height

2100 mm

Width

720 mm

Length

1093 mm
