- The drum of the machines and doors are stainless steel and the side panels are electrostatic powder painted over steel sheet material.
- Optionally; side panels are produced from stainless steel.
- “Stainless steel drum sheet has been perforated specially with special molds to prevent clothes damages.”
- Except user friendly control panel; our machines have different options: microprocessor or colored touch screen PLC unit is available to set; dryer time, humidity and temperature.
- The heating system is produced in steam or electric type.
- The stainless-steel drum is isolated with aluminum foil glass wool to prevent heat loss.
- As an option; the door is locked for safety when the machine is running.
- Extra Large door opening for easy loading and unloading.
- Very large filter easy to clean. As an option; clogged filter warning system.
- Optionally; manufactured with cool-down system.
- Produced according to TS EN 10472-1, TS EN 10472-4 and EN 60204-1 standards.
- Produced according to 98/37/EEC – Machine Safety regulations, 73/23/EEC LVD – Low Voltage Regulations and 89/339/EEC – Electromagnetic Compatibility Regulations.
- Our machines have; TSE, CE, GOST-R quality and security certificates.
- Our machines are specifically designed for a minimum service requirement and low maintenance costs.
- By the special design; easy to use, safe operation, low noise level, providing low power consumption and high efficiency.
- As an option; the coin unit will be available for 10 and 15 KG capacities.
|
Model |
KCKM – E/40 |
KCKM- E/50 |
KCKM-E/60 |
KCKM- E/80 |
KCKM- E/100 |
|
Product Code |
8004040102 |
8004050102 |
8004060102 |
8004080102 |
8004100102 |
|
Model |
KCKM-B/40 |
KCKM-B/50 |
KCKM-B/60 |
KCKM-B/80 |
KCKM-B/100 |
|
Product Code |
8004040108 |
8004050108 |
8004060108 |
8004080108 |
8004100108 |
|
Capacity, KG/Load |
40 |
50 |
60 |
80 |
100 |
|
Drum Diameter, mm |
Ø 1130 |
Ø 1130 |
Ø 1130 |
Ø 1300 |
Ø 1300 |
|
Drum Volume, Lt. |
850 |
1050 |
1200 |
1550 |
1700 |
|
Electrical Hearing, kW |
26 |
30 |
32 |
39 |
42 |
|
Operating System Pressure**, atm |
0,4-4 |
0,4-4 |
0,4-4 |
0,4-4 |
0,4-4 |
|
Steam Consumption**, KG/hour |
53 |
57 |
60 |
85 |
105 |
|
Motor Power, HP-kW |
2 – 1,5 |
3 – 2,2 |
3 – 2,2 |
4 - 3 |
4 - 3 |
|
Supply Voltage |
380 – 415 V, 3N, ph, 50-60 Hz |
||||
|
Cross Section of Wires*, mm2 |
4*6 |
4*10 |
4*10 |
4*16 |
4*16 |
|
Cross Section of Wires**, mm2 |
4*2.5 |
4*4 |
4*4 |
4*4 |
4*4 |
|
Steam Inlet, inch |
1” |
1 1/4 “ |
1 1/4 “ |
1 1/2 “ |
1 1/2 “ |
|
Condenser Inlet, inch |
3/4” |
1” |
1” |
1” |
1” |
|
Width, mm |
1220 |
1220 |
1220 |
1220 |
1220 |
|
Depth, mm |
1250 |
1470 |
1600 |
1650 |
1900 |
|
Height, mm |
1900 |
2110 |
2110 |
2200 |
2200 |
|
Weight, Kg |
480 |
550 |
650 |
850 |
1050 |
|
Installation |
Fastened on a fixed ground |
||||
|
*: Electrical **: Steam |
|||||
